AS410
4X4 Dual Band 802.11ac Wave 2
Supports IEEE 802.11ac Wave 2 Standard
High-density applications with MU-MIMO technology
Ultra fast data rate up to 2533Mbps
Passpoint R2 Certification
Description
The AS410 is a high-density, high-performance, and high-capacity wireless access point. With MU-MIMO technology to support four space streams, the highest data rate can be up to 2.5Gbps. The AS410 can be centrally managed by remote Z-COM WLC (Wireless LAN Controller).
Flexible and diverse installation, the AS410 is suitable for any scene in the desktop, ceiling, wall and other installation methods.
Multiple Management Choices
Besides performing as a stand-alone access point, the AS410 can be centrally managed by remote WLC (Wireless LAN Controller) which also provides Wi-Fi user authentication, traffic shaping, user and bandwidth controls, and statistics reporting
Ultra-fast Data Rate
Deliver higher data rates up to 2533Mbps over a greater area with pervasive coverage than any competing access point
MU-MIMO Technology
Simultaneously stream data to multi-devices for high-density applications.
Improved User Experience
Supports Hotspot 2.0 and authenticates every connection, which avoids connecting inconvenience. Enable a more cellular-like user experience while connecting to Wi-Fi networks.
Advanced Security
Support WPA-PSK/WPA2-PSK with 802.1x Authentication.
Specification
| Standards | IEEE 802.11b/g/n IEEE 802.11an/ac |
| Radio Chains | 2.4GHz: 4x4:4 5GHz: 4x4:4 |
| Supported Data Rates | 802.11b: 1, 2, 5.5, 11 Mbps 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n: 800Mbps 802.11ac: 1733Mbps |
| Bandwidth | 20 / 40 / 80 MHz |
| Frequency Bands | IEEE 802.11b/g/n US: 2.412GHz – 2.462GHz EU/Japan: 2.412 – 2.472 GHz China/India: 2.412 – 2.472 GHz IEEE 802.11an/ac US: 5.15GHz – 5.35GHz 5.47GHz – 5.85GHz EU/Japan: 5.15GHz – 5.35GHz 5.47GHz – 5.725GHz China: 5.15GHz – 5.35GHz 5.725GHz – 5.85GHz India: 5.15GHz – 5.35GHz 5.725GHz – 5.85GHz 5.85GHz – 5.875GHz |
| Operating Channels | 2.4GHz: US: 1 – 11 EU/Japan/China/India: 1 – 13 5GHz: US: 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 132, 136, 140, 149, 153, 157, 161, 165 EU/Japan: 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 132, 136, 140 China: 36, 40, 44, 48, 52, 56, 60, 64, 149, 153, 157, 161, 165 India: 36, 40, 44, 48, 52, 56, 60, 64, 49, 153, 157, 161, 165, 169, 173 |
| Max. Transmit Power | 2.4GHz: 28dBm 5GHz: 28dBm |
| Min. Receive Sensitivity | -103dBm |
| Antenna | 2.4GHz: 4dBi (Embedded) 5GHz: 5dBi (Embedded) |
| Dimensions | 216 (L) × 216 (D) × 43 (H) mm |
| Weight | 800g |
| Certifications | CE RoHS |
| Interfaces | 2 auto MDX, auto-sensing 10/100/1000 Mbps, RJ45, POE port (on one port) 1 Reset button 1 Console |
| Power Input | 802.3at (PoE+) |
| Power Consumption | < 25.5W |
| Indicator | Power / WLAN / LAN1 / LAN2 |
| Mounting | Ceiling Wall-mount |
| Operating | Temperature: -10 – 50 ℃ Humidity: 10 – 90% (non-condensing) |
| Storage | Temperature: -20 – 70 ℃ Humidity: 10 – 90% |
| Operating Mode(s) | TAP: Controller-managed mode FAP: Standalone AP mode |
| Access Method | Web User Interface Telnet SSH SNMP |
